UCFC216 Round Flange Housing 4 Bolt Ball Bearing

down load to pdf

Details

Tags

UCFC216 Round Flange Housing 4 Bolt Ball BearingUCFC216 Round Flange Housing 4 Bolt Ball Bearing



d
80 mm
 Bore diameter
H
240 mm
 Height flange
U
67.3 mm
 Total height unit
Cr
76,000 N
 Basic dynamic load rating, radial
C0r
54,000 N
 Basic static load rating, radial
Cur
2,190 N
 Fatigue load limit, radial
≈m
8.8 kg
 Weight
J
200 mm
 Distance fixing bore
J
200 mm
 Pitch circle diameter (holes)
N
23 mm
 Fixing bore
N1
141.4 mm
 Distance fixing bore
T1
16 mm
 Height spigot
Z
170 mm
 Diameter spigot

h8
 Diameter spigot clearance
n
4
 Number of screwing holes
A
42 mm
 Height housing
A1
18 mm
 Thickness of flange
A2
18 mm
 Distance raceway
B
82.8 mm
 Width
Q
M6
 Connection thread for lubrication
Tmin
-20 °C
 Operating temperature min.
Tmax
120 °C
 Operating temperature max.
