When mounting the clutch on a shaft, apply pressure to the clutch inner race end, but never to the outer race.
Proper selection of the Cam Clutch provides accurate indexing performance. A braking device and a backstopping device may also be required for more accurate performance.
The tolerance of the hub bore should be H6 or H7.
Model |
Torque |
Max.Indexing |
Bore Size |
A |
B |
C |
PCD |
E |
F |
S |
H-MNo.ofTapped Holes |
Lubrication |
InertiaInner Race (kg·m2) |
Drag |
Oil |
Weight |
|
Dia. |
Keyway |
||||||||||||||||
MX22 |
78.4 |
1200 |
22 |
6 × 2.8 |
80 |
95 |
77 |
80 |
12 |
35 |
16 |
4XM8XP1.25 |
M6XP1.0 |
0.00015 |
0.47 |
80 |
3.3 |
MX35 |
235 |
1200 |
35 |
10 ×33 |
90 |
125 |
87 |
110 |
12 |
50 |
16 |
4XM8XP1.25 |
M6XP1.0 |
0.000625 |
1.36 |
110 |
6.4 |
MX50 |
441 |
1200 |
50 |
14 × 3.8 |
100 |
155 |
97 |
140 |
14 |
70 |
16 |
6XM8XP1.25 |
M8XP1.25 |
0.00275 |
2.68 |
190 |
10.6 |
MX70 |
784 |
1200 |
70 |
20 ×4.9 |
127 |
200 |
124 |
180 |
15 |
100 |
20 |
6XM8XP1.25 |
M8XP1.25 |
0.0130 |
5.15 |
340 |
21.3 |
