Features:
1. Self contained clutch designed for high speed applications.
2. Cam cage assembly engineered for optimum performance and increased capacity.
3. Two ball bearings included to support radial load and concentricity between races.
4.Positive contact lip or felt seals provided for grease or oil lubrication.
5.Tapped holes are machined on ends of outer race for mounting auxiliary components.
6.Metric bore and keyway available.
7.Mounting accessories available.
Dimensions and Capacities:
Model |
|
|
Max. |
|
|
|
|
|
|
|
|
|
H-M |
|
|
|
||
Inner Race |
Outer Race |
Dia. |
Keyway |
(h7) |
D |
|||||||||||||
MG 300 |
314 |
0.23 |
2800 |
900 |
_ |
19 |
5x2 |
63 |
77 |
60 |
66 |
10.4 |
28.5 |
13 |
4xM6xP1.0 |
M6xP1.0 |
25 |
1.8 |
MG 400 |
539 |
0.29 |
2600 |
800 |
_ |
22 |
5x2 |
70 |
88 |
67 |
73 |
10.7 |
31.7 |
16 |
4XM8xP1.25 |
M6xP1.0 |
30 |
2.7 |
MG 500 |
1620 |
0.51 |
2400 |
800 |
_ |
31.5 |
7x3 |
89 |
108 |
86 |
92 |
12.3 |
44.4 |
16 |
4XM8xP1.25 |
M6xP1.0 |
50 |
5.0 |
MG 600 |
3140 |
0.85 |
2100 |
700 |
_ |
50 |
12x3.5 |
95 |
136 |
92 |
120 |
12.8 |
69.8 |
16 |
6xM8xP1.25 |
M6xP1.0 |
80 |
8.6 |
MG 700 |
5880 |
1.70 |
1500 |
500 |
_ |
70 |
18x6 |
127 |
180 |
124 |
160 |
19.8 |
101.5 |
20 |
6xM10xP1.5 |
M6xP1.0 |
135 |
19.5 |
MG 750 |
9500 |
3.43 |
1800 |
600 |
_ |
85 |
24x6 |
153 |
200 |
150 |
175 |
75 |
110 |
25 |
8xM14xP2.0 |
M8xP1.25 |
400 |
37.0 |
MG 800 |
17600 |
5.39 |
1300 |
475 |
_ |
110 |
28x7 |
158 |
250 |
155 |
220 |
77.5 |
140 |
25 |
8xM16xP2.0 |
M8xP1.25 |
500 |
46.5 |
MG 900 |
24500 |
6.77 |
1200 |
400 |
_ |
135 |
35x9 |
165 |
300 |
160 |
265 |
80 |
170 |
32 |
10xM16xP2.0 |
M8xP1.25 |
620 |
70.5 |
MG 1000 |
33800 |
8.14 |
1200 |
325 |
_ |
160 |
38x10 |
188 |
370 |
180 |
325 |
90 |
200 |
32 |
12xM16xP2.0 |
M8xP1.25 |
850 |
108.5 |
MG 1100 |
78400 |
15.00 |
350 |
_ |
_ |
185 |
45x14 |
260 |
470 |
250 |
415 |
125 |
260 |
40 |
12xM20xP2.5 |
M12xP1.75 |
2900 |
250 |
MG 1200 |
95100 |
17.64 |
300 |
_ |
_ |
200 |
45x14 |
260 |
500 |
250 |
440 |
125 |
280 |
45 |
12xM24xP3.0 |
M12xP1.75 |
3000 |
280 |
MG 1300 |
176000 |
18.72 |
250 |
_ |
_ |
250 |
56x17.5 |
280 |
600 |
260 |
530 |
130 |
340 |
50 |
12xM30xP3.5 |
M12xP1.75 |
3800 |
410 |
