CKS Two Way Wedge Ovrrunning Clutch For Printing Brush Machinery

Usually used on Printing machine, Packing machine, Hoisting machine, Lifting transportation machinery, etc.

Details

Tags

Product description:
CKS is Two way SPRAG TYPE ovrrunning clutch;
Working as BACKSTOP Application ;
Usually used on Printing machine, Packing machine, Hoisting machine, Lifting transportation machinery, etc.

Mounting Example:

CKS Two Way Wedge Ovrrunning Clutch For Printing Brush Machinery

Type	Clutch Size						Flange Size						Torque capacity
Type	d	D	T	C	b1	t1	D1	D2	D3	H	h	d1	(N.m)
CKS70(42)X58-10	10	32	51	20	3	1.4	70	55	42	58	11	6.5	20
CKS75(45)X58-10	10	35	52	20	3	1.4	75	60	45	58	11	6.5	20
CKS75(45)X58-12	12	35	51	20	4	1.8	75	60	45	58	11	6.5	20
CKS75(45)X58-15	15	35	51	20	3	1.4	75	60	45	58	11	6.5	20
CKS95(57)X78-17	17	47	70	27	5	2.3	95	75	57	78	13	8.5	50
CKS105(62)X78-20	20	52	70	27	6	2.8	105	84	62	78	16	10.5	100
CKS115(74)X78-20	20	62	70	27	6	3.3	115	95	74	78	16	10.5	100
CKS115(74)X78-25	25	62	80	32	8	3.3	115	95	74	88	16	10.5	120
CKS125(84)X100- 30	30	72	90	37	8	3.3	125	105	84	100	16	10.5	150
CKS132(88)X100-30	30	75	90	35	8	3.3	132	110	84	100	16	10.5	150
CKS145(94)X110-35	35	80	100	40	10	3.3	145	120	94	110	20	13	200
CKS155(102)X110-40	40	85	100	40	12	3.3	155	128	102	110	20	13	250
CKS160(108)X120-45	45	90	110	45	14	3.8	160	134	108	120	20	13	300
