UKT217 Take Up Housing Bearing Unit Pillow Block Bearing

Details

Tags

Housing units UKT, cast iron housing, radial insert ball bearing with adapter sleeve, RSR seals, for linear motion





d
75 mm
Bore diameter
H
198 mm
Height
L
260 mm
Length total
B1
82 mm
Locking collar total width
≈m
11,2 kg
Weight
A1
30 mm
Width guidance groove

0,3 mm
Upper width guidance groove tolerance

0 mm
Lower width guidance groove tolerance
H1
173 mm
Distance guidance grooves

0 mm
Upper distance guidance groove tolerance

-0,8 mm
Lower distance guidance groove tolerance
N
48 mm
Fixing bore
L1
162 mm
Distance shaft axis
L2
29 mm
Length fixed link
L3
157 mm
Length guidance groove
A
73 mm
Width housing fixing side
N1
38 mm
Width recess
N2
73 mm
Height recess
T
124 mm
Height housing fixing side
Q
M6
Connection thread for lubrication
A2
54 mm
Width housing
 Tmin
-20 °C
Operating temperature min.
Tmax
100 °C
Operating temperature max.
