Housing units UKT, cast iron housing, radial insert ball bearing with adapter sleeve, RSR seals, for linear motion
d |
65 mm
|
Bore diameter |
H |
167 mm
|
Height |
L |
232 mm
|
Length total |
B1 |
73 mm
|
Locking collar total width |
≈m |
7,69 kg
|
Weight |
A1 |
26 mm
|
Width guidance groove |
0,3 mm
|
Upper width guidance groove tolerance | |
0 mm
|
Lower width guidance groove tolerance | |
H1 |
151 mm
|
Distance guidance grooves |
0 mm
|
Upper distance guidance groove tolerance | |
-0,8 mm
|
Lower distance guidance groove tolerance | |
N |
41 mm
|
Fixing bore |
L1 |
140 mm
|
Distance shaft axis |
L2 |
21 mm
|
Length fixed link |
L3 |
121 mm
|
Length guidance groove |
A |
70 mm
|
Width housing fixing side |
N1 |
32 mm
|
Width recess |
N2 |
70 mm
|
Height recess |
T |
111 mm
|
Height housing fixing side |
Q |
M6
|
Connection thread for lubrication |
A2 |
48 mm
|
Width housing |
Tmin |
-20 °C
|
Operating temperature min. |
Tmax |
100 °C
|
Operating temperature max. |
