Housing units UKT, cast iron housing, radial insert ball bearing with adapter sleeve, RSR seals, for linear motion

UKT210 Take Up Housing Bearing Unit Pillow Block Bearing

d	45 mm	Bore diameter
H	117 mm	Height
L	149 mm	Length total
B₁	55 mm	Locking collar total width
≈m	2,7 kg	Weight
A₁	16 mm	Width guidance groove
	0,2 mm	Upper width guidance groove tolerance
	0 mm	Lower width guidance groove tolerance
H₁	102 mm	Distance guidance grooves
	0 mm	Upper distance guidance groove tolerance
	-0,5 mm	Lower distance guidance groove tolerance
N	29 mm	Fixing bore
L₁	90 mm	Distance shaft axis
L₂	16 mm	Length fixed link
L₃	86 mm	Length guidance groove
A	49 mm	Width housing fixing side
N₁	19 mm	Width recess
N₂	49 mm	Height recess
T	83 mm	Height housing fixing side
Q	M6	Connection thread for lubrication
A₂	37 mm	Width housing
T_min	-20 °C	Operating temperature min.
T_max	100 °C	Operating temperature max.
