Housing units UKT, cast iron housing, radial insert ball bearing with adapter sleeve, RSR seals, for linear motion
d |
40 mm
|
Bore diameter |
H |
117 mm
|
Height |
L |
144 mm
|
Length total |
B1 |
50 mm
|
Locking collar total width |
≈m |
2,5 kg
|
Weight |
A1 |
16 mm
|
Width guidance groove |
0,2 mm
|
Upper width guidance groove tolerance | |
0 mm
|
Lower width guidance groove tolerance | |
H1 |
102 mm
|
Distance guidance grooves |
0 mm
|
Upper distance guidance groove tolerance | |
-0,5 mm
|
Lower distance guidance groove tolerance | |
N |
29 mm
|
Fixing bore |
L1 |
87 mm
|
Distance shaft axis |
L2 |
16 mm
|
Length fixed link |
L3 |
83 mm
|
Length guidance groove |
A |
49 mm
|
Width housing fixing side |
N1 |
19 mm
|
Width recess |
N2 |
49 mm
|
Height recess |
T |
83 mm
|
Height housing fixing side |
Q |
M6
|
Connection thread for lubrication |
A2 |
35 mm
|
Width housing |
Tmin |
-20 °C
|
Operating temperature min. |
Tmax |
100 °C
|
Operating temperature max. |
