UKF205 Pillow Housings Pillow Block Bearing

Details

Tags

d
20 mm
Bore diameter
L
95 mm
Flange width
Cr
14.000 N
Basic dynamic load rating, radial
C0r
7.800 N
Basic static load rating, radial
Cur
410 N
Fatigue load limit, radial
≈m
0,9 kg
Weight
J
70 mm
Distance fixing bore
N
12 mm
Fixing bore
n
4
Number of screwing holes
A
27 mm
Height housing
A1
14 mm
Thickness of flange
A2
16 mm
Distance raceway
B
23 mm
Width
B1
35 mm
Locking collar total width
d3
38 mm
Outside diameter eccentric locking collar
Tmin
-20 °C
Operating temperature min.
Tmax
120 °C
Operating temperature max.
