UCFC217 Round Flange Housing 4 Bolt Ball Bearing



d
85 mm
 Bore diameter
H
250 mm
 Height flange
U
69.6 mm
 Total height unit
Cr
88,000 N
 Basic dynamic load rating, radial
C0r
64,000 N
 Basic static load rating, radial
Cur
2,490 N
 Fatigue load limit, radial
≈m
10.38 kg
 Weight
J
208 mm
 Distance fixing bore
J
208 mm
 Pitch circle diameter (holes)
N
23 mm
 Fixing bore
N1
147.1 mm
 Distance fixing bore
T1
18 mm
 Height spigot
Z
180 mm
 Diameter spigot

h8
 Diameter spigot clearance
n
4
 Number of screwing holes
A
45 mm
 Height housing
A1
20 mm
 Thickness of flange
A2
18 mm
 Distance raceway
B
85.7 mm
 Width
Q
M6
 Connection thread for lubrication
Tmin
-20 °C
 Operating temperature min.
Tmax
120 °C
 Operating temperature max.
