UCFC216-49 Round Flange Housing 4 Bolt Ball Bearing

Details

Tags



d
77,787 mm
Bore diameter
H
240 mm
Height flange
U
67,3 mm
Total height unit
Cr
76.000 N
Basic dynamic load rating, radial
C0r
54.000 N
Basic static load rating, radial
Cur
2.190 N
Fatigue load limit, radial
≈m
8,95 kg
Weight
J
200 mm
Distance fixing bore
J
200 mm
Pitch circle diameter (holes)
N
23 mm
Fixing bore
N1
141,4 mm
Distance fixing bore
T1
16 mm
Height spigot
Z
170 mm
Diameter spigot

h8
Diameter spigot clearance
n
4
Number of screwing holes
A
42 mm
Height housing
A1
18 mm
Thickness of flange
A2
18 mm
Distance raceway
B
82,8 mm
Width
Q
M6
Connection thread for lubrication
Tmin
-20 °C
Operating temperature min.
Tmax
120 °C
Operating temperature max.
