UCFC210-30 Round Flange Housing 4 Bolt Ball Bearing

down load to pdf

Details

Tags

UCFC210-30 Round Flange Housing 4 Bolt Ball BearingUCFC210-30 Round Flange Housing 4 Bolt Ball Bearing

d
47,625 mm
 Bore diameter
H
165 mm
 Height flange
U
42,6 mm
 Total height unit
Cr
35.000 N
 Basic dynamic load rating, radial
C0r
23.200 N
 Basic static load rating, radial
Cur
990 N
 Fatigue load limit, radial
≈m
2,983 kg
 Weight
J
138 mm
 Distance fixing bore
J
138 mm
 Pitch circle diameter (holes)
N
16 mm
 Fixing bore
N1
97,6 mm
 Distance fixing bore
T1
12 mm
 Height spigot
Z
110 mm
 Diameter spigot

h8
 Diameter spigot clearance
n
4
 Number of screwing holes
A
28 mm
 Height housing
A1
14 mm
 Thickness of flange
A2
10 mm
 Distance raceway
B
51,6 mm
 Width
Q
M6
 Connection thread for lubrication
Tmin
-20 °C
 Operating temperature min.
Tmax
120 °C
 Operating temperature max.
