UCFC209-26 Round Flange Housing 4 Bolt Ball Bearing

down load to pdf

Details

Tags

UCFC209-26 Round Flange Housing 4 Bolt Ball BearingUCFC209-26 Round Flange Housing 4 Bolt Ball Bearing

d
41,275 mm
 Bore diameter
H
160 mm
 Height flange
U
40,2 mm
 Total height unit
Cr
32.500 N
 Basic dynamic load rating, radial
C0r
20.400 N
 Basic static load rating, radial
Cur
870 N
 Fatigue load limit, radial
≈m
2,761 kg
 Weight
J
132 mm
 Distance fixing bore
J
132 mm
 Pitch circle diameter (holes)
N
16 mm
 Fixing bore
N1
93,3 mm
 Distance fixing bore
T1
12 mm
 Height spigot
Z
105 mm
 Diameter spigot

h8
 Diameter spigot clearance
n
4
 Number of screwing holes
A
26 mm
 Height housing
A1
14 mm
 Thickness of flange
A2
10 mm
 Distance raceway
B
49,2 mm
 Width
Q
M6
 Connection thread for lubrication
Tmin
-20 °C
 Operating temperature min.
Tmax
120 °C
 Operating temperature max.
