Our heavy duty disc harrow bearings are made with tripple lip seals to protect from corrosive environments. This seal is a one piece shroud cover with three molded contact seals. Standard relubrication feature is drilled hole in groove.
Disc Harrow Bearings are specially designed for disc harrow applications, in agricultural farm machinery, where a robust assembly is necessary to cope with the arduous conditions. Disc Harrow Bearings are available with a square, round or hexagonal bore.
Dimensions: | |
A: |
1-1/4" Suare |
B: |
85mm Curved Re-Lube |
C: |
1.438" |
D: |
0.866" |
THIS BEARING UNIT IS ALSO KNOW AS:
BCA/FEDERAL MOGUL: DS209TTR8
FAFNIR/TORRINGTON: GW209PPB8
LINK BELT: 20SG5-209E3
