6028 High Quality Deep Groove Ball Bearing 140X210X33

down load to pdf

Details

Tags

Deep groove ball bearing 60, single row, steel sheet metal cage

d
140 mm
 Bore diameter
D
210 mm
 Outside diameter
B
33 mm
 Width
Cr
117.000 N
 Basic dynamic load rating, radial
C0r
109.000 N
 Basic static load rating, radial
Cur
5.100 N
 Fatigue load limit, radial
nG
4.250 1/min
 Limiting speed
nϑr
4.050 1/min
 Reference speed
≈m
3,57 kg
 Weight
da min
148,8 mm
 Minimum diameter shaft shoulder
Da max
201,2 mm
 Maximum diameter of housing shoulder
ra max
2 mm
 Maximum fillet radius
rmin
2 mm
 Minimum chamfer dimension
D1
187,54 mm
 Shoulder diameter outer ring
d1
162,28 mm
 Shoulder diameter inner ring
Tmin
-30 °C
 Operating temperature min.
Tmax
150 °C
 Operating temperature max.
f0
16
 Calculation factor



High quality bearing manufacturer from China, special bearings can be customized, welcome to inquire!
