Name: 6208 High Quality Deep Groove Ball Bearing 40X80X18
Brand: Spherical Roller Ceramic Deep Groove Bearing Ball Suppliers Manufacturers Factory
Availability: InStock
Rating: 4.5 (89 reviews)

6208 High Quality Deep Groove Ball Bearing 40X80X18

હમણાં સંપર્ક કરો પીડીએફમાં ડાઉનલોડ કરો

વિગતો

ટૅગ્સ

Deep groove ball bearing 62, single row, steel sheet metal cage

સંબંધિત ઉત્પાદનો

30305-A High Quality Tapered Roller Bearing
30304-A High Quality Tapered Roller Bearing
30303-A High Quality Tapered Roller Bearing
30226-XL High Quality Tapered Roller Bearing
30224-XL High Quality Tapered Roller Bearing
30222-XL High Quality Tapered Roller Bearing
30221-A High Quality Tapered Roller Bearing
30220-A High Quality Tapered Roller Bearing

d	40 mm	Bore diameter
D	80 mm	Outside diameter
B	18 mm	Width
C_r	31.000 N	Basic dynamic load rating, radial
C_0r	17.800 N	Basic static load rating, radial
C_ur	1.080 N	Fatigue load limit, radial
n_G	12.300 1/min	Limiting speed
n_ϑr	9.300 1/min	Reference speed
≈m	353 g	વજન
d_{a min}	47 mm	Minimum diameter shaft shoulder
D_{a max}	73 mm	Maximum diameter of housing shoulder
r_{a max}	1 mm	Maximum fillet radius
r_min	1,1 mm	Minimum chamfer dimension
D₁	67,6 mm	Shoulder diameter outer ring
D₂	70,36 mm	Caliber diameter outer ring
d₁	52,95 mm	Shoulder diameter inner ring
T_min	-30 °C	Operating temperature min.
T_max	120 °C	Operating temperature max.
f₀	14	Calculation factor
