6415-M High Quality Deep Groove Ball Bearing 76X190X45

Luchdaich a-nuas pdf gu pdf

Mion-fhiosrachadh

Tagaichean

Deep groove ball bearing 64..-M, single row, solid brass cage

d
75 mm
 Bore diameter
D
190 mm
 Outside diameter
B
45 mm
 Width
Cr
141.000 N
 Basic dynamic load rating, radial
C0r
97.000 N
 Basic static load rating, radial
Cur
6.000 N
 Fatigue load limit, radial
nG
6.600 1/min
 Limiting speed
nϑr
5.600 1/min
 Reference speed
≈m
7 kg
 Cuideam
da min
91 mm
 Minimum diameter shaft shoulder
Da max
174 mm
 Maximum diameter of housing shoulder
ra max
2,5 mm
 Maximum fillet radius
rmin
3 mm
 Minimum chamfer dimension
D1
151,58 mm
 Shoulder diameter outer ring
d1
114,38 mm
 Shoulder diameter inner ring
Tmin
-30 °C
 Operating temperature min.
Tmax
150 °C
 Operating temperature max.
f0
13,3
 Calculation factor



High quality bearing manufacturer from China, special bearings can be customized, welcome to inquire!
